1/2 Psh Bu-Wh Supply Vlv With Etsv (H-62652W)
by Nibco
Pro-Pal valves are your best choice for efficient installation and system operation, and for helping to control costs. Pro-Pal Valves combine commonly used components into a single forged brass alternatives that will save time and space in any installation. Instead of just building your next piping system, innovate it with Pro-Pal Series Valves. The Pro-Pal Water Heater Supply Valve combines multiple components into a single, forged DZR brass solution to upgrade your next water heater installation. Designed for use with water in residential or commercial plumbing systems. Refer to specification
Product Specification
Item #
H-62652W
Dimensions
Additional product details
Vendor Item #
H-62652W
AltImageName1
/NBC/High_Res_RGB_JPG-H-8265W.jpg
AltImageName2
/NBC/webimage-H-6265W.jpg
AltImageName3
/NBC/webimage-H-8265W.jpg
AltImageName4
/NBC/thul-H-6265W.jpg
AltImageName5
/NBC/thul-H-8265W.jpg
AltImagePath1
/NBC-High_Res_RGB_JPG-H-8265W.JPEG
AltImagePath2
/NBC-webimage-H-6265W.JPEG
AltImagePath3
/NBC-webimage-H-8265W.JPEG
AltImagePath4
/NBC-thul-H-6265W.JPEG
AltImagePath5
/NBC-thul-H-8265W.JPEG
Bullet10
This valve is actuated by a blowout proof stem.
Bullet11
Double O-ring Stem Seals
Bullet12
Models available to satisfy all state and federal low-lead laws
Bullet13
Patents Pending
Bullet14
Available in FIP Union x SWT, FIP Union x PSH, FIP Union x PRS, FIP Union x MIP, FIP Union x FIP
Bullet15
Certified to NSF/ANSI/CAN 61 & 372
Bullet5
1/2'' FIP port for installation of vacuum relief valve and 1/8'' plugged gauge port
Bullet6
Compatible with 3/4'' MIP expansion tanks up to 5 gallons - Compact version available if expansion tank is not required
Bullet7
Includes support hardware
Bullet8
Compact version available if expansion tank is not required
Bullet9
Saves 135 Minutes, Replaces 16 Components, Eliminates 15 Leakpaths
Country
China
Description
Pro-Pal Water Heater Supply Valve, w/ Expansion Tank Service, Full Port DZR Brass Ball w/ Union End, w/ 3/4 Expansion Tank Port and Hi-Flow Hose Drain, (3) Plugged FIP Ports (1/2'', 1/2'' and 1/8''), Includes Mounting Hardware
Height
2.44
Length
12.2
Material
LF DZR Brass
Minimum Order Quantity
1
Prop65
This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Ship Weight
3.7
Shipping Height
2.76
Shipping Length
12.2
Shipping Width
5.43
Spec Sheet
UOM
Each
Weight
3.4
Width
5.12
Manufactured By
Nibco
